Je bekijkt pagina 6 van 19
6
NI
Description of the parts
Housing cover for lubrication
On / Off Switch
Function selector switch
Unlocking mechanism for drilling /
hammer drilling / chiselling
Anti- vibration handle
Speed regulator
GREEN LED Indicator
RED LED indicator
Additional handle
Tool holder
Locking sleeve
Locking latch for the depth stop
Keyed chuck
Chuck key
Depth stop
Key for lubricating the housing cover
Accessories (tool) (suitable for use with
SDS+ system)
- 1 pointed chisel
- 1 flat chisel
- 3 drill bits (12, 16 & 18 mm)
Grease for tool inserts
3
1
4
2
5
6
7
8
9
14
15
16
17
18
12
13
11
10
2. Technical data
Model No.: PBH 1550 A1
Mains connection 230-240 V
~
/ 50 Hz
Rated power 1550 W
Idling speed 0 - 800 min
-1
Blows per minute 0 - 3900 min
-1
Impact energy 5,0 Joule
Chuck Chuck suitable for use
with SDS+ system
Keyed chuck 1.5 - 13 mm
Max drilling
capacity
32 mm (concrete)
32 mm (brickwork)
13 mm (steel)
40 mm (wood)
Protection class II
Scope of use
This drill is exclusively designed for private
use and for hobby and DIY projects for the
following purposes:
Drilling:
- Drilling metal, wood and plastic.
Hammer drilling:
- Drilling concrete, stone, granite,
brickwork and similar materials.
Chiselling:
- Chiselling brickwork and masonry.
The hammer drill has to be used properly as
specified. Any other use is forbidden. The
manufacturer cannot be held responsible
for damage or injury caused by use the
machine for other than its intended purpose.
Only accessories which are suitable for
the drill may be used. Non-observance
of the safety, assembly and operating
instructions while operating the appliance
counts as misuse. Anyone who operates or
services the drill must be familiar with these
instructions and must be aware of possible
dangers. Any applicable health and safety
regulations must also be followed.
Any other applicable local and national
legislation must also be followed. The drill
may not be modified. The manufacturer
can accept no responsibility for damage or
injury caused by modifications to the drill.
The drill has not been designed for
professional, trade or industrial use, but for
private users in the hobby and DIY sector.
Any other use of the product is expressly
forbidden and is considered as misuse.
3. Safety
