PAGHS 20-Li A1
■ 2
│
GB
│
IE
│
NI
Introduction
Congratulations on the purchase of your new tool.
You have chosen a high-quality product. The
operating instructions are a part of this product.
They contain important information about safety,
usage and disposal. Before using the product,
please familiarise yourself with all instructions
regarding safety and use. Use the product only as
described and for the specified range of applica-
tions. Please also pass on all documents to any
future owner.
Intended use
The tool is intended for cutting wood.
Use this tool only as described and for the areas of
applications specified. The tool is not intended for
commercial use. Any other usage or modification
of the tool is deemed to be improper and carries a
significant risk of accidents. The manufacturer
accepts no responsibility for damage attributable
to misuse.
Features
1 Fastening screw
2 Chain sprocket cover
3 Safety lock-out
4 ON/OFF switch
5 Saw chain
6 Blade
7 Hole for chain tensioner
8 Chain tensioner
9 Chain sprocket
0 Protective cover
q Charger*
w Battery pack
e Oil bottle
* BATTERY AND CHARGER ARE NOT SUPPLIED
Package contents
1 20V cordless pruning saw
1 protective cover
1 50 ml bottle of organic chain oil
1 set of operating instructions
Technical data
Rated voltage 20 V (DC)
Max. chain speed 8m/s
Guide rail DS06-38-43P-BM
Saw chain D43-S-38-BM
Chain pitch 6.35 mm
Drive link thickness 1.27 mm
Number of teeth on
the chain sprocket 38
Guide rail length 192 mm
Usable cut length/
guide rail 160 mm
The tool is part of the Parkside
series
and can be operated using Parkside
batteries.
Batteries from the Parkside
series may
only be charged using Parkside series
chargers.
We recommend that you only operate this tool
with the following batteries:
PAP20A1/PAP20A2/PAP20A3/
PAP20B1/PAP20B3/Smart PAPS204A1/
SmartPAPS208A1.
We recommend that you charge these batteries
with the following chargers:
PLG 20 A3/PLG 20 A4/PLG 20 C1/PLG 20 C3/
PDSLG 20 A1/Smart PLGS 2012 A1.
