PAGHS 20-Li A1
■ 8
│
GB
│
IE
│
NI
Before use
Charging the battery pack (see Fig. C)
WARNING!
► Observe the safety instructions and the
instructions on charging and correct use
given in the operating instructions for your
X20 Team series battery and charger.
A detailed description of the charging pro-
cess and further information can be found
in these separate operating instructions.
CAUTION!
► Always unplug the tool before you remove
the battery pack from or connect the battery
pack to the charger.
NOTE
► The battery is partially charged. Ideally,
charge the battery completely before use.
You can charge the lithium-ion battery at any
time without shortening its service life. Inter-
rupting the charging process does not dam-
age the battery.
► Never charge the battery pack if the ambient
temperature is below 10°C or above 40°C.
If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level
is between 50% and 80%. The storage climate
should be cool and dry and the ambient tem-
perature should be between 0°C and 50°C.
► The recommended ambient temperature range
for using tools and batteries is between –5°C
and 50°C.
♦ If necessary, remove the battery from the tool.
♦ Push the battery pack w into the high-speed
charger q.
♦ Insert the mains plug into the mains socket.
♦ When charging is complete, disconnect the
charger q from the mains.
♦ Pull the battery pack w out of the high-speed
charger q.
♦ Switch off the charger for at least 15 minutes
between successive charging sessions. Also
disconnect the mains plug.
Replacing the blade or saw chain
WARNING!
► Wear protective gloves! There is a risk of
injury from the sharp cutting teeth!
♦ The chain running direction indicator
on the blade 6 must be complied with dur-
ing every assembly.
♦ Loosen the fastening screw 1 of the chain
sprocket cover 2 in the direction of the
symbol. Remove the chain sprocket cover 2.
♦ Carefully lift the blade 6 to disengage it
from the chain tensioner 8.
♦ Replace the blade 6 or the saw chain 5.
♦ Place the saw chain 5 on the blade 6. Note
the running direction
of the saw chain 5.
♦ Position the hole 7 for the chain tensioner
above the chain tensioner 8.
♦ Press the blade 6 towards the chain sprocket 9.
♦ Place the saw chain
5
around the chain
sprocket
9.
♦ Reattach the chain sprocket cover 2 and
tighten the fastening screw 1 in the direction
of the
symbol.
Tightening and checking the saw
chain
WARNING!
► Wear protective gloves! There is a risk of
injury from the sharp cutting teeth!
The chain tension will be set automatically by a
spring in the chain tensioner 8.
♦ The saw chain 5 must lie against the underside
of the blade. Check whether the saw chain 5
can be drawn by hand over the blade 6.
