7 GB/IE/NI
Delivery contents
Always verify the parts are complete and the product
is in perfect condition immediately after unpacking.
1 Handle piece
2 Spotlights
2 Clamping nuts with 3 washers each
(mounting bracket) (pre-installed)
1 Mounting bracket
2 Screws with 2 washers (mounting bracket)
(pre-installed)
1 Tripod
1 Clamping nut (tripod) (pre-installed)
1 Screw (handle) (pre-installed)
1
Set of assembly instructions and instructions for us
e
Parts description
1
Handle piece
2
Spotlight
3
Wing bolt
4
Clamping nut (mounting bracket)
5
Mounting bracket
6
Screw (mounting bracket)
7
Mains cable bracket
8
Clamp
9
Height adjuster
10
Tripod
11
Clamping nut (tripod)
12
Cable winder
13
Screw (handle)
14
Mains cable
15
ON / OFF switch
Technical data
Model number: FCL-80115UK
Operating voltage: 220–240 V
~
50 Hz
Light bulb: LED 2 x max. 30 W
Rated power max.: 2 x max. 30 W
Protection type: IP65
Spotlight dimensions: approx. 195 x 62 x 158 cm
Height of tripod
including spotlight: up to approx. 170 cm
Cable length: 3 m
Cable type: HO7RN-F 3G 1.0 mm²
Light colour: 4000 K
Total luminous flux: 2 x 2400 lm, Ra > 65
adjustable beam angle: 107 °
luminous flux at
120° angle: approx. 2 x 2100 lm
Weight: 5.2 kg
Projected area: 2 x 164 cm²
Safety instructions
DANGER TO
LIFE AND RISK OF ACCIDENTS
FOR INFANTS AND CHILDREN!
This product can be used by children aged 8
years and up, as well as by persons with reduced
physical, sensory or mental capabilities or who
lack experience and knowledge if they have
been given supervision or instruction concerning
use of the product in a safe way and if they un-
derstand the hazards involved. Do not allow
children to play with the product. Cleaning and
user maintenance must not be performed by
children without supervision.
Do not leave the light or packaging material
lying unattended. Plastic film/bags, plastic parts,
etc. are dangerous for children to play with.
AVOID THE RISK OF FATAL IN-
JURY FROM ELECTRIC SHOCK
We assume no liability for property damage
or personal injury due to improper handling or
failure to observe the safety notices!
Never use the light if any damages have been
detected. Check the light and the mains cable
14
with the plug for any damage before connecting
it to the mains.
Never open any of the electrical equipment or
insert objects into these. This will pose the risk
of fatal injury from electric shock.
Touch only the insulated part of the plug when
connecting to or disconnecting from the mains
supply!
To avoid hazards, if the flexible lead on this
light is damaged it must be replaced by the
