Trigger adjustments
1. Duplex screw “1” controls the 2nd stage of the trigger pull. Turning the outer body
clockwise increases the LENGTH of the 2nd stage. (If turned counterclockwise far
enough, the 2nd stage disappears.) Turning the inner screw clockwise increases the
WEIGHT of the 2nd stage.
2. Screw “2” acts as a trigger stop or overtravel adjustment. Turning it clockwise reduces
the over travel. Too far in, and the sear cannot be released.
3. Screw “3” and “4” should only be adjusted by qualified technicians to avoid damage
to the pistol or unsafe operation! Screw 3 adjusts the trigger pull length and screw 4
regulates the sear engagement.
UNLOADING THE PISTOL
1. Depress the magazine release catch and remove the magazine.
2. Pull back the slide to eject any chambered cartridge.
3. Visually verify that there are no rounds left in the chamber or the magazine well before
closing the slide.
Technical data
LOCKING SYSTEM: Modified Browning. Short action recoiling barrel,
steel frame insert with barrel locking ramp. Frame: CNC milled one piece
construction. Ergonomic characteristics: 115 degree grip angle, high grip
(6,2 mm below slide rails) for straight back recolling.
SLIDE: CNC milled with large ejection port for improved case clearing.
SIGHTS: Interchangeable front sights and micrometer adjustable rear sight
sitting flush with the slide.
TRIGGER: Single action trigger with adjustable sear engagement, trigger
pull weight and take-up and overtravel adjustments.
SAFETY: Ambidextrous thumb safety that locks both sear and slide.
