Gain Switch

The Gain switch has two positions Low (23dB) and Normal (29dB). This switch would typically be left in the

Normal position. If you have very high sensitivity speakers or your preamp already has very high gain,

then you should use the Low setting.

Examples of when to use the Low (23dB) Gain setting:

• You have very high sensitivity speakers (typically above 96dB sensitivity).

• The volume control on your preamp ramps up too fast.

• You can hear some background hiss in your speakers.

Audio Input & Output Connections

Balanced XLR Input Jacks

In most systems balanced XLR connections will give you the best quality sound because of their ability to

reject noise. Refer to the Balanced and Unbalanced Lines in the Technically Speaking section for additional

information and why we recommend using balanced lines.

Note: Using balanced XLR input connectors results in a 6 dB higher volume level compared with using the

RCA input jacks. This is a noticeable level increase.

Unbalanced RCA Input Jacks

Use these inputs if your preamplifier doesn’t have balanced XLR output connectors or if you simply prefer

to use unbalanced connections.

Balanced/Unbalanced Selector Switch

Place the switch in the position for the input type you will be using.

Note: The Balanced/Unbalanced switch is not an input selector. Its function is purely to optimize the signal to

noise ratio for each type of input. You should not connect both the Balanced and Unbalanced jacks at the

same time with the expectation of switching between two different devices such as a preamp and a

surround processor.

Balanced XLR Pin Configuration

The JCA100 XLR jacks conform to the industry standard of:

• Pin 1: Ground

• Pin 2: Positive (+)

• Pin 3: Negative (–).

XLR and RCA Output Jacks

These Output jacks enable the incoming audio signal to pass along or “daisy chain” the incoming audio

signal to an additional amplifier for bi-amping or for connecting a powered subwoofer. The XLR input signal is

available at both the XLR and RCA Output jack. The XLR and RCA Output jacks are not affected by the Gain

switch setting.
