INSTALLATION INSTRUCTIONS
© Panduit Corp. 2024
V00029TB_06INSTALLATION INSTRUCTIONS
For Technical Support: www.panduit.com
T70 Raceway knock-out
(top & bottom)
Rack Units for Patch Panels
(view shown with door removed)
Combination 1/2" or 3/4"
knock-out (2 plcs. top & bottom)
Combination 1" or 1 1/4"
knock-outs (6 plcs. top & bottom)
Removable Top Lid
Reversible door hinges
Wall pass-thru knock-out
Multiple conduit box
mounting locations
Removable bottom plate
Removable plates for
additional cable capacity
(2 plcs.)
Perforated for airflow
Perforated for airflow
Combination 1 1/2" or 2"
knock-outs (2 plcs. both sides)
T70 Raceway knock-out
(2 plcs. both sides)
Combination 1/2" or 3/4"
knock-out (1 plc, both sides)
Reversible door latch
Adjustable Horizontal active E-rails
(#12-24 & cage nut)
Perforated fan knock-outs
Side Brackets for
mounting E-rails
Page 3 of 16
