© Panduit Corp. 2018
OPERATION MANUAL
PES400
ENGLISH
PES400: PA28981A01_01 Page: 7 of 51 4-2018
1.4.2 Install Software for the USB to Serial Adapter (XP, Vista, 2000)
a. Insert the Flash Drive that came with the PES400 into the USB port on the
target computer.
b. If the auto start runs the installation go to Step 6, if not continue.
c. Click on the My Computer icon, either on the desktop or click Start and then
My Computer.
d. Double-click on the icon for the Flash Drive to display the files.
e. Find the Autorun.exe or Setup.exe file and double-click on it.
f. Select the option to install the USB to Serial Adapter you have with the
Windows version you are running.
g. Connect the USB to serial cable to serial cable from embosser and USB port
on computer. Reboot if prompted to reboot.
1.4.3 Windows 7, 8 and 10
a. Connect the USB to serial cable to serial cable from embosser and USB port
on computer.
b. Operating system will automatically download the driver.
1.5 Install External Hopper
1. Use the 2 screws provided to mount external hopper. Place the screw heads to the
outside, nuts and washers to the inside of the embosser.
2. Slide hopper back and forth on screws to line up divider in 0.75” (19mm) slot, see
[Figure 24], with side eject guide plate @ 0.75” (19mm) see [Figure 23].
3. Tighten screws to lock hopper position.
1.6 Easy-Mark Plus™ Software Installation
***Version 1.2 or higher is required to operate the PES400 Embossing System***
SYSTEM REQUIREMENTS:
