For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2012
CM546B
Page 5 of 14
Cage Nut Installation
Insert (4) cage nuts per equipment rail at 9506 component mounting locations (16 total cage nuts are to be installed). (1) grounding cage nut
(green) must be
installed in each equipment rail. The view below depicts cage nut location for (1) front intended mounting location, and (1)
rear mounting location.
Front E-Rail Cage Nut Locations
Rear E-Rail Cage Nut Locations
Cage Nuts
(installed)
Cage Nuts
(installed)
Intended
Mounting
Location
(3 rack
spaces)
Intended
Mounting
Location
(3 rack
spaces)
