17
English
Specifications
∫ TV
Model No.
: TV-55Z95BP
: TV-65Z95BP
: TV-77Z95BP
Display Panel
Panel System
OLED panel
Refresh Rate
144 Hz
Screen size
55″ class (54.6 inches measured diagonally)
65″ class (64.5 inches measured diagonally)
77″ class (76.6 inches measured diagonally)
W × H × Diagonal
1,210 mm × 680 mm × 1,388 mm (47.6″ × 26.7″ × 54.6″)
1,428 mm × 804 mm × 1,639 mm (56.2″ × 31.6″ × 64.5″)
1,697 mm × 955 mm × 1,947 mm (66.8″ × 37.5″ × 76.6″)
Number of pixels
3,840 × 2,160
Sound
Speaker output
160 W (70 W + 15 W × 2 + 15 W × 2 + 30 W × 1)
170 W (80 W + 15 W × 2 + 15 W × 2 + 30 W × 1)
180 W (90 W + 15 W × 2 + 15 W × 2 + 30 W × 1)
Headphones / Subwoofer
3.5 mm stereo mini jack × 1
Channel Capability (Digital)
VHF / UHF: 2 - 69, CATV: 1 - 135
DTV Tuner
ATSC / ATSC 3.0 (NEXTGEN TV)
Operating conditions
Temperature
0 °C - 35 °C (32 °F - 95 °F)
Humidity
20 % - 80 % RH (non-condensing)
Connection terminals
HDMI 1 / 2 / 3 / 4 input
TYPE A Connectors
HDMI 1:
4K144Hz, VRR (Variable Refresh Rate), NVIDIA
®
G-
SYNC
®
Compatible, AMD FreeSync™ Premium,
Content Type, Deep Color, x.v.Color™
HDMI 2:
4K144Hz, VRR (Variable Refresh Rate), NVIDIA
®
G-
SYNC
®
Compatible, AMD FreeSync™ Premium,
Content Type, eARC (Enhanced Audio Return Channel)
/ ARC (Audio Return Channel), Deep Color, x.v.Color™
HDMI 3 / 4:
4K, Content Type, Deep Color, x.v.Color™
≥ This TV supports “HDAVI Control 5” function.
ETHERNET
10BASE-T / 100BASE-TX
≥ Use Shielded Twist Pair (STP) LAN cable.
USB 1 / 2 / 3
USB 1 / 3: DC 5 V, Max. 500 mA [Hi-Speed USB
(USB 2.0)]
USB 2: DC 5 V, Max. 900 mA [SuperSpeed USB
(USB 3.0)]
DIGITAL AUDIO OUT
PCM / Dolby Audio, Fibre optic
IR blaster
3.5 mm mini jack × 1
Built-in wireless LAN
Standard compliance and Frequency band
IEEE802.11ax: 6 GHz band
IEEE802.11a/n/ac/ax: 5 GHz band
IEEE802.11b/g/n/ax: 2.4 GHz band
Security
WPA3-SAE (AES)
WPA2-PSK (TKIP/AES)
WPA-PSK (TKIP/AES)
WEP (64 bit/128 bit)
Bluetooth
®
wireless technology*
Standard Compliance and Frequency band
Bluetooth
®
5.3: 2.4 GHz band
Not all the Bluetooth
®
compatible devices are available with
this TV. Up to 5 devices can be used simultaneously.
<Note>
≥ Design and Specifications are subject to change without notice.
Mass and Dimensions shown are approximate.
≥ For the information about the power source and power
consumption, refer to the nameplate on the rear enclosure.
≥ For information about the open source software, refer to
[Panasonic eHELP] (Search by Purpose > Read first > Before
use > Licence).
55-inch model
65-inch model
77-inch model
55-inch model
65-inch model
77-inch model
55-inch model
65-inch model
77-inch model
55-inch model
65-inch model
77-inch model
