Handleiding
Je bekijkt pagina 27 van 32
English - 26 -
2
3
1
1. Broadband ISP connection
2. LAN (Ethernet) cable
3. LAN input on the rear side of the TV
You might be able to connect your TV to a network
wall socket depending on your network’s conguration.
In that case, you can connect your TV directly to the
network using an Ethernet cable.
1
2
1. Network wall socket
2. LAN input on the rear side of the TV
Wireless Connection
A wireless LAN modem/router is required to connect
the TV to the Internet via wireless LAN.
Highlight Enable Network option in the Network
menu and press Select to enable wireless connection.
Then disconnect the Ethernet cable, if connected
priorly. Some of the available networks will be listed.
Highlight See All Networks and press Select to see
the complete list.
If you prefer to connect your TV to your network via
WLAN you have 3 ways to do this.
• Highlight one of the listed available wireless networks
and press Select. Then enter the password if the
network is password protected.
• Use the WPS button on your router. Highlight Join
Network Using WPS (Button) option and press
Select. Press the WPS button on your router. Your
TV will connect to your router, without the use of a
password.
Note: During the initial setup process Connect using
WPS Push Button option will be available instead of Join
Network Using WPS (Button) option.
• Enter WPS PIN on your router. Highlight Join
Network Using WPS (PIN) option and press Select.
A code will be created and displayed on the screen.
Enter this code on your router. Your TV will connect
to your router, without the use of a password.
Note: During the initial setup process Connect using WPS
PIN option will be available instead of Join Network Using
WPS (PIN) option.
1
1. Broadband ISP connection
A network with hidden SSID can not be detected by
other devices. If you want to connect to a network
with hidden SSID, highlight the Join Other Network
option under the Network menu and press Select.
Add the network by entering its name, security type
and password manually. If you want to configure
additional settings of the network manually, highlight
Advanced when prompted and press Select. Follow
the on-screen instructions to proceed and enter the
required values respectively.
If you want to save the wireless network passwords
to Amazon you can use the Save Wi-Fi Passwords
to Amazon option. To delete saved passwords turn
this option o.
A Wireless-N router (IEEE 802.11a/b/g/n/ac) with 2.4
and 5 GHz bands is designed to increase bandwidth.
These are optimised for smoother and faster HD video
streaming, le transfers and wireless gaming.
Use a LAN connection for quicker data transfer
between other devices like computers.
The transmission speed diers depending on the
distance and number of obstructions between the
transmission products, the configuration of these
products, the radio wave conditions, the line trac
and the products that you use. The transmission may
also be cut o or may get disconnected depending
