English - 19 -
and Options menus may be available depending on
the media file type and the model of your TV and its
features. The content of these menus may also differ
according to the type of the currently open media file.
Only the Sound Settings menu will be available while
playing back audio files.
Loop/Shuffle Mode Operation
Start playback and activate
All files in the list will be
continuously played in
original order
Start playback and activate
The same file will be
played continuously
(repeat)
Start playback and activate
All files in the list will be
played once in random
order
Start playback and activate
,
All files in the list will be
continuously played in
the same random order
To use the functions on the information bar highlight the
symbol of the function and press OK. To change the
status of a function highlight the symbol of the function
and press OK as much as needed. If the symbol is
marked with a red cross, that means it is deactivated.
Custom Boot Up Logo
You can personalise your TV and see your favourite
image or photo on the screen each time your TV boots
up. To do this, copy your favourite image files onto a
USB disk and open them in the Media Browser. Select
USB input from the Sources menu on the Home
screen and press OK. You can also press the Source
button on the remote and then select your USB storage
device from the list of sources. When you have chosen
the desired image, highlight it and press OK to view
it in full screen. Press the Info button, highlight the
gear wheel symbol on the information bar and press
OK. Select Options and press OK to enter. Set Boot
Logo option will be available. Highlight it and press
OK again to choose the image as custom boot logo.
A confirmation message will be displayed. Select Yes
and press OK again. If the image is suitable (*) you
will see it on the screen during the TV’s next boot up.
Note: You can use the Restore Default Boot Logo option in
the Settings>System>More menu to restore the default boot
logo. If you perform First Time Installation the boot logo will
also be restored to its default.
(*) Images must have an aspect ratio between 4:3 to 16:9
and they must be in .jpeg or .jpg file formats. The image
cannot be set as boot logo, if its resolution doesn’t appear
on the info banner.
FollowMe TV
With your mobile device you can stream the current
broadcast from your smart TV using the FollowMe
TV feature. Install the appropriate Smart Center
application to your mobile device. Start the application.
For further information on using this feature refer to
the instructions of the application you use.
Note: Depending on model, your TV may not support this
function. The application may not be compatible with all mobile
devices. Both of the devices must be connected to the same
network. This feature is only functional on TV source.
CEC
This function allows the user to control the CEC-
enabled devices, that are connected through HDMI
ports by using the remote control of the TV.
The CEC option in the Settings>Devices menu should
be set as Enabled at first. Press the Source button
and select the HDMI input of the connected CEC
device from the Sources List menu. When a new
CEC source device is connected, it will be listed in
Sources List menu with its own name instead of the
connected HDMI port’s name (such as DVD Player,
Recorder 1, etc.).
The TV remote is automatically able to perform the
main functions after the connected HDMI source has
been selected. To terminate this operation and control
the TV via the remote again, press and hold the “0-
Zero” button on the remote control for 3 seconds.
You can disable the CEC functionality by setting the
related option under the Settings>Devices menu
accordingly.
The TV supports ARC (Audio Return Channel). This
feature is an audio link meant to replace other cables
between the TV and an audio system (A/V receiver or
speaker system).
When ARC is active, the TV will mute its other audio
outputs, except the headphone jack, automatically and
volume control buttons are directed to the connected
audio device. To activate ARC set the Sound Output
option in the Settings>Sound menu as HDMI ARC.
Note: ARC is supported only via the HDMI2 input.
Enhanced Audio Return Channel (eARC)
Similar to ARC, the eARC feature enables the transfer
of the digital audio stream from your TV to a connected
audio device via the HDMI cable. eARC is an improved
version of ARC. It has a much higher bandwidth than
its predecessor. Bandwidth represents the range of
frequencies or amount of data that is being transferred
at a time. Higher bandwidth translates into a higher
amount of data that can be transferred. Higher
bandwidth also means that digital audio signal doesn’t
have to be compressed and is much more detailed,
rich, and vibrant.
