7
DP-0
Type Low pressure High pressure
Model No.
NPN output DP-001 DP-002
Item PNP output DP-001-P DP-002-P
Type of pressure Gauge pressure
Rated pressure range −100.0 to +100.0 kPa 0.000 to +1.000 MPa
Set pressure range
−101.0 to +101.0 kPa
−1.030 to +1.030 kgf/cm
2
−1.010 to + 1.010 bar
−14.65 to +14.65 psi
−756 to +756 mmHg
−0.010 to +1.010 MPa
−0.1 to +10.30 kgf/cm
2
−0.1 to + 10.10 bar
−0.1 to +146.5 psi
Pressure withstandability 500 kPa 1.5 MPa
Applicable uid Air, non-corrosive gas
Selectable unit Low pressure type: kPa, kgf/cm
2
, bar, psi, mmHg High pressure type: MPa, kgf/cm
2
, bar, psi
Supply voltage 12 to 24 V DC ±10 % Ripple P-P 10 % or less
Power consumption 30 mA or less
Comparative output
<NPN output type>
NPN open-collector transistor
• Maximum sink current: 50 mA
• Applied voltage: 30 V DC or less
(between comparative output and 0 V)
• Residual voltage: 2 V or less (at 50 mA sink current)
<PNP output type>
PNP open-collector transistor
• Maximum source current: 50 mA
• Applied voltage: 30 V DC or less
(between comparative output and +V)
• Residual voltage: 2 V or less (at 50 mA source current)
Output operation Selectable either NO or NC by key operation
Hysteresis Minimum 2 digits (variable)
Repeatability ±0.2 % F.S. (within ±4 digits) ±0.4 % F.S. (within ±4 digits)
Response time 2.5 ms, 25 ms, 250 ms, selectable by key operation
Short-circuit protection
Incorporated
Display 3 + 1/2 digits, 3-color (white / red / pink) LCD display (Display update period: 250 ms)
Displayable
pressure range
−101.0 to +101.0 kPa
−1.030 to +1.030 kgf/cm
2
−1.010 to + 1.010 bar
−14.65 to +14.65 psi
−756 to +756 mmHg
−0.010 to +1.010 MPa
−0.1 to +10.30 kgf/cm
2
−0.1 to + 10.10 bar
−0.1 to +146.5 psi
Environmental resistance
Protection IP40 (IEC)
Ambient temperature 0 to +50 °C +32 to +122 °F (No dew condensation allowed), Storage: -10 to +60 °C +14 to +140 °F
Ambient humidity 35 to 85 % RH, Storage: 35 to 85 % RH
Voltage withstandability 500 V AC for one min. between all supply terminals connected together and enclosure
Insulation resistance 50 MΩ or more with 500 V DC megger between all supply terminals connected together and enclosure
Vibration resistance
10 to 150 Hz frequency, amplitude 0.75 mm 0.030 in or maximum acceleration 49 m/s
2
, in X, Y and Z directions for two hours each
Shock resistance 100 m/s
2
acceleration (10 G approx.) in X, Y and Z directions for three times each
Pollution degree 2
Overvoltage category I
Usable altitude 2,000 m 6,562 ft or less
Temperature characteristics
(+20°C standard)
+10 to +40°C +50 to +104°F: Within ±1 % F.S.
0 to +50°C 32 to +122°F: Within ±2.5 % F.S.
+10 to +40°C +50 to +104°F: Within ±2 % F.S.
0 to +50°C 32 to +122°F: Within ±5 % F.S.
Grounding method Floating
Pressure port M5 female thread
Material
Enclosure: PBT (glass ber reinforced), LCD display: Acrylic, Pressure port: Brass (nickel plated),
Mounting threaded part: Brass, O-ring: Nitrile rubber (NBR), Key section: Polycarbonate
Weight 25 g approx.
Accessory CN-14A-C2 (Connector attached cable 2 m 6.562 ft): 1 pc.
Note: Where measurement conditions have not been specied precisely, the conditions used were an ambient temperature of +20 °C +68 °F.
SPECIFICATIONS
