DIGITAL OUT
4
Power connector
(page 40)
R (Red)
Video
(Yellow)
Video
(Yellow)
L (White)
(Black)
7
RCA cord
Preout cord (front)
RCA cord
(option)
CQ-DF903U (option)
R (Red)
R (Red)
CX-D3000U (rear)
L (White)
L (White)
AUX input cord
VIDEO OUT
AUDIO OUT
REMOTE IN
AUX-IN
FRONT
REMOTE- OUT
COLOR LCD MONITOR
VM5800
STAND BY(R) /ON(G)
CY-VM5800U
Display unit (option)
Remote control signal receiver lead
VTR-IN
Video input lead
RCA cord
(option)
(Black)
AUX-IN
By performing this connection,
remote control signals can be
received by the monitor unit.
(Do not connect the remote
control signal receiver when
this connection has been per-
formed.)
Examples combination
≥ Rear seat monitor
(CY-VM5800U, option)
≥ Digital surround processor (CY-AC300, option)
≥Power amplifier (CY-M9054 or CY-M7052, option)
≥ CD player/receiver with CD changer control
(CQ-DF903U, option)
≥ Center speaker (EAB-CF2, option)
Electrical Connections (continued)
E
N
G
L
I
S
H
33
CX-D3000U
4242
❐ Upgrading the system
