16
Installation and connections
(Be sure to ask your dealer.)
1Turn off the power of the unit, and disconnect the power cable.
2Loosen the four screws of SLOT A or SLOT B at the back of the unit, and remove the blank panel.
Screw
Blank panel
Screw
SLOT A
SLOT B
3Align the optional unit with the guide rails, and insert it slowly.
Insert it until it will go no further. Take care not to exert excessive force while doing this since that may damage the connector
inside.
4Mount the optional unit in place using the four screws.
Clamping torque: 0.7 N•m
Screw
Screw
5After connecting the necessary cables, plug the power cable into the power outlet, and turn on the power.
