9
9
STEREO
Switch for switching the STEREO INPUT L / R signal input on and o. When the input is switched on,
the corresponding display LED lights up.
10
AUX / BLUETOOTH
®
Switch to switch the AUX signal input and Bluetooth
®
on and o. When the input is switched on,
the corresponding display LED lights up. The AUX input and Bluetooth
®
can be used simultaneously.
11
BLUETOOTH
®
PAIR
Button to start the pairing process with a Bluetooth-enabled smart device (smartphone, tablet). Press and
hold the button for approx. 2 seconds until the blue Bluetooth LED flashes. The Bluetooth unit now remains
ready for pairing for approx. 120 seconds. Activate Bluetooth on your smart device and search for available
devices on the user interface. Select the “Monicon L” entry and use it to pair your smart device with the
Bluetooth unit of the monitor controller. If successfully paired, the Bluetooth LED will light up permanently,
and audio playback can begin.
12
VOLUME AUX / BLUETOOTH
®
Volume control for the line inputs and the Bluetooth unit. The volume control is located in the signal path
before the MAIN volume control. The AUX inputs and the Bluetooth unit can be used simultaneously if required.
13
MAIN
Volume control for adjusting the listening volume.
14
1 – 2 – 3
Switch for switching the line outputs OUT 1, 2 and 3 on and o. When an output is switched on,
the corresponding display LED lights up. All outputs can be used simultaneously.
15
PFL MAIN & AUX / BLUETOOTH
®
Switch for switching the signal source for the PHONES headphone output.
Switch not pressed: MAIN signal source.
Switch pressed: AUX / Bluetooth
®
signal source.
16
PHONES
Stereo headphone output with a 6.35mm TRS jack socket.
17
PHONES LEVEL
Volume control for the headphone output (le stop = output muted, right stop = maximum volume).
The headphone signal is tapped before the MAIN volume control and is therefore independent of it.
CAUTION: Using the headphone output can produce high sound pressure levels (SPL) that may cause
hearing damage. Avoid exposure to high volumes!
