EN
4
STEREO INPUT L / R
Stereo input with two balanced XLR / 6.35mm TRS jack combo sockets. Use a high-quality stereo cable to
connect an audio interface, studio mixer or similar to the stereo input. Ensure the correct channel
assignment (OUTPUT L INPUT L, OUTPUT R INPUT R).
5
AUX INPUT L / R
Unbalanced stereo input with two RCA sockets and one 3.5mm stereo mini jack socket. Do not use the
inputs simultaneously. Use a high-quality stereo cable to connect an audio interface, studio mixer, or similar
to the stereo input. Ensure the correct channel assignment (OUTPUT L INPUT L, OUTPUT R INPUT R).
6
OUT 1 L / R
Separately switchable stereo line output with two balanced XLRm sockets. Use a high-quality stereo cable to
connect the stereo output to active studio monitors or a studio power amplifier. Ensure the correct channel
assignment (OUTPUT L INPUT L, OUTPUT R INPUT R).
7
OUT 2 L / R
Separately switchable stereo line output with two balanced XLRm sockets. Use a high-quality stereo cable to
connect the stereo output to active studio monitors or a studio power amplifier. Ensure the correct channel
assignment (OUTPUT L INPUT L, OUTPUT R INPUT R).
8
OUT 3
Separately switchable mono line output with one balanced XLRm socket. Use a high-quality audio cable to
connect the mono output to an active studio subwoofer or a studio power amplifier.
9 1110
13
12
18 19
20
15
17
16
14
