3.Quick Start
4
⑤
Function keys
CONF : Opens the configuration page for system
function settings.
EXIT : Exits to the previous screen.
DISP : Switches between numerical output display and
waveform display.
LOCK : Short press this button to lock the panel keys.
When locked, pressing any other key will have no
effect. Hold this button for more than 5 seconds to
unlock.
⑥
Channel button
CH1, CH2, CH3, CH4 channel button, press it to select
this channel.
⑦
On/Off button
Press the On/Off button of the corresponding channel
to turn the channel output on or off.
⑧
USB Host port
Connect as a "host device" with an external USB
device, such as connect a USB disk to the instrument.
⑨
CH4 output
terminals
Channel 4 output connectors.
⑩
CH3 output
terminals
Channel 3 output connectors.
⑪
Ground
terminal
Channel ground connector.
⑫
CH2 output
terminals
Channel 2 output connectors.
⑬
CH1 output
terminals
Channel 1 output connectors.
⑭
Power button
Turn on/off the instrument
Instructions for panel key indicator
ON/OFF key: Press the button, and the channel light and the button light will
turn on.
