22
will not trigger the current On/Off state.
Software Over Power Protection: When the software over-power
protection function is turned on, if the load power exceeds the over-power
protection setting value and lasts for 100ms, the load will automatically
turn off and the panel will display OPP. In order to ensure the reliability of
the machine, if the load power abnormally exceeds 2 times the rated
maximum current of the machine for 40us or 1.1 times the rated current
for 100us, the fast software over-power protection is triggered, the load
will automatically turn off and the panel will display OPP. Users can set
the software over-power protection value of the load. For related
configuration items, please refer to F1 to enter the parameter setting.
Over Temperature Protection (OTP)
When the internal devices’ temperature of the electronic load exceeds about
85°C, the electronic load would trigger the temperature protection mode, and
the electronic load automatically turns OFF and the panel displays OTP.
Local Reverse Voltage Protection (LRV)
When the electronic load detects a reverse voltage input on the front panel, it
will trigger the Local Reverse Voltage (LRV) protection warning. In this case,
please confirm that the front panel input terminals are correctly connected to
the device under test. It can be released by pressing the power button or the
ENTER button.
Fault Type
ERROR CODE
Fault cause Description
MAINS AC
FAULT
0x0002
Abnormal mains undervoltage
INTERNAL
FAULT
0x0004
Over temperature protection
0x0010
Error in internal parameter storage
0x0020
Model firmware match error
OUTPUT
FAULTS
0x0002
Output over voltage protection
0x0008
Output over current protection
0x0010
Output over power protection
0x0004
Local Reverse Voltage Protection
PARALLEL
FAULTS
0x0001
Parallel address conflict
0x0002
Multiple master fault
0x0008
Communication drop
0x0010
Mismatch in operable unit fault
