20
FALL
SLOPE
The setting value for the fall rate of input voltage or
current during load operation.
CURRENT
LIMIT
The maximum current value that can be set for
normal load operation.
REMOTE
COMPENS
ATION
This option allows enabling the remote sensing
function at the rear terminals, with the default setting
for compensation at the front panel input terminals.
VOLTAGE
RANGE
The input voltage range supported by the electronic
load is as follows:
Low range: 0-15V
High range: 0-150V
LOAD
VOLTAGE
After the load is connected, normal load operation
can occur once the input voltage reaches the set
load voltage.
Figure 4-7-2 parameters setup page
4.8 Protection Functions and Fault Information
Products monitor the internal operation of the machine in real time, including
system logic faults, external mains power faults, internal power stage faults
such as OVP (Over Voltage Protection), OCP (Over Current Protection), OPP
(Over Power Protection), OTP (Over Temperature Protection), as well as
parallel operation faults, input reverse voltage protection, etc.
When any of the above protections are triggered, the electronic load enters
the corresponding self-protection mode. For example, in the case of over-
temperature protection, the load will trigger an alarm and automatically switch
