Panel Layout and Device Features
70
your cameras, media servers and other inputs without the need for an external audio
mixer. This saves space and makes low cost as you don’t need separate audio
connections for each video source.
The audio source buttons are MIC1, MIC2, IN1, IN2, IN3, IN4 and AUX, as shown in
Figure 4.1-59. IN1, IN2, IN3, IN4 is corresponding to the embedded audio of HDMI1 to
HDMI4 respectively(or SDI1~SDI4), MIC1 and MIC2 is corresponding to analog audio
media respectively, and AUX is corresponding to the embedded audio of the video
source coming from SD card.
PGM represents the mixed audio output using the other audio sources.
Figure 4.1-59 Buttons in Audio Mix Area
◼
Audio Mix-ON and AFV
The cooperation of ON, AFV and audio sources buttons determines whether
audio is always available for mixing or only when the corresponding video source
is on air.
Selecting ON option automatically disables AFV, and selecting AFV option
automatically disables the direct mix ON setting.
The cooperation relationship of button ON and AFV are list in the following table:
Button
ON
AFV
MIC1
MIC2
IN1
IN2
