Panel Layout and Device Features
34
4.1.3 Panel Operations
4.1.3.1 Display Multiview
Plug an HDMI television or monitor into your switcher’s HDMI OUT2 connector so you
can monitor your multiview.
Multiview features monitoring all input sources and outputs on one single screen
simultaneously. This multiview is the default HDMI output source through OUT2
connector.
As shown in Figure 4.1-20, you can monitor up to 10 views, including program output,
preview output, four HDMI inputs, four SDI inputs, AUX input, two still images and
audio levels plus streaming status, recording time and free space in SD card. And you
can load the main menu on multiview to set the specific settings for the device.
Figure 4.1-20 Multiview Display
Multiview is the default output source for OUT2 interface and is composed of 10
views.
After connecting signals, the multiview interface is as shown in Figure 4.1-21:
