Panel Layout and Device Features
33
Group
Button
Comment
Function Description
selected, a transition from the current source on
the program bus to the source selected on the
preview bus will occur without the keyer, and
BKGD button is highlighted in white.
Press BKGD again, only the keyer will occur in
the transition, leaving the current background
live throughout the transition, BKGD button
turns gray.
The upstream keyer can be configured as a luma key, chroma key, pattern key or
PIP key. Set the KEY type in "5.1.3Key Type" menu.
Refer to "5.1.4 LUMA Key " for details about Luma Key parameter settings.
Refer to "5.1.5 Chrome Key " for details about Chroma Key parameter settings.
Refer to "5.1.6 Key Pattern " for details about Pattern Key parameter settings.
Refer to "5.1.7 PIP " for details about PIP Key parameter settings.
Refer to "5.1.9 DSK Settings" for details about DSK parameter settings.
Color for Next Transition Control Buttons:
The status for the button colors in Next transition area are described in the
following table:
Button
Button color
Description
Default color
Effective color
ON AIR
White
Highlighted Red
Upstream Keyer is on air
KEY
White
Highlighted White
Upstream Keyer will change its former
status in next transition
ON AIR
White
Highlighted Red
Downstream Keyer is on air
KEY
White
Highlighted White
Downstream Keyer will change its
former status in next transition
BKGD
White
Highlighted White
Background will change its former
status in next transition
