Functionalities and Operations
32
3. Output Settings
Select the output format through the Output Settings frame, as shown in
Figure 3.2.8:
Figure 3.2.8 Output Format
◼ Resolution
Click the resolution item, it will show the drop list for output format in
property pane: 1080i50
,
1080i60
,
1080P50
,
1080P60,
2160P25,
2160P30
,
2160P50, 2160P60.
◼ UHD Config
Set output mode. HD SDI uses Dual-Link as default.
UHD Config: Single-Link or Four-Link, and the Four-Link only
supports 2SI mode.
◼ The relationship between output format and output connector are as
shown in the table below:
Output format
Single-Link
Dual-Link
Four-Link
1080i50
--
SDI1/SDI2
HDMI1/HDMI2
1080i60
--
SDI1/SDI2
HDMI1/HDMI2
1080P50
--
SDI1/SDI2
HDMI1/HDMI2
1080P60
--
SDI1/SDI2
HDMI1/HDMI2
2160P25
SDI1
HDMI1
--
2160P30
SDI1
HDMI1
--
