Startup and Software Interface
11
Refer to “3.2 System Configuration” for the details about system
configuration.
2.3.2 Input Configuration Window
Click
IN
P
UT
tab in the title bar, it will display the input
configuration workplace, as shown in Figure 2.3.5, it is used to modify the
signal source name, create the mapping relationship between the audio
channel and audio meter, configure UMD, video and audio alarms.
Figure 2.3.5 Input Configuration Window
1. Device pane in input configuration window
It provides the device list as the same as in the system window, no further
details in this part.
2. Working area for input list
The inputs information for the current device is listed in a table.
The Input List includes: SDI IN
, Source Name, Audio Type, CH1/2,
CH3/4, UMD Type
,
UMD ID
,
Video Loss Alarm
,
Audio Loss Alarm
,
Video Black Alarm
,
Video Black Limit1
, and
Video Black Limit2
, as
shown in
Figure 2.3.6
:
