EN - 21
left side of the sliding button.
Then press ‘A’ and ‘B’ buttons at the same
time for 2-3 seconds to set the selected
limit. Now the hob is ready to use with the
new power limit setting.
This setting can be made at any time and is
maintained until the next change.
In the image above, the front right heater
display is indicating the chocolate-melting
function.
Performance and time may vary
according to the quantity of food in the
pan and the quality of the pan. 1.5
litres of water or 0.5 litres of oil gives the
best cooking performance with these
functions.
Error Codes
If there is an error, an error code will be shown on
the heater displays.
E0
Ampere limit feature must be selected
at the moment the product is energized.
Otherwise E0 error is seen. At the same
time, this feature should be selected on the
display and mainboard. If there is an error
in the software of any card, the product
will show an error. The customer cannot
interfere
in this error. Authorized service should be
called.
E1
Cooling Fan is disabled. Call an authorised
service agent.
E2
This error is seen when the heater gets
too hot. In case of this error, the heater
must be cooled. It should be operated after
cooling, again.
E3
Supply voltage is other than the rated
values. Switch the hob off by pressing
,wait until “H” disappears for all zones,
switch the hob on by pressing and
continue to use. If the same error is
displayed again, call an authorised service
agent.
E4
Supply frequency is different from the rated
values. Switch the hob off by pressing
, wait until “H” disappears from all
zones, switch the hob on by pressing
and continue to use. If the same error is
displayed again, switch the plug for the
appliance off and on. Switch the hob on
by pressing and continue to use. If the
same error is displayed again, call an
authorised service agent.
E5 Internal temperature of the hob is too high,
switch the hob off by pressing and let the
heaters cool down.
E6
Communication error between the touch
control and heater. Call an authorised
service agent.
E7
Coil temperature sensor is disabled. Call
an authorized service agent.
E8
Cooler temperature sensor is disabled. Call
an authorized service agent.
EA Large Coil Saturation Error. Switch the hob
off by pressing on/off button, switch the hob
on by pressing on/off button and continue
to use. If the same error is displayed again,
call an authorised service agent.
EC Supply Voltage Error.Switch the hob off by
pressing on/off button, switch the hob on by
pressing on/off button and continue to use.
If the same error is displayed again, call an
authorised service agent.
C1-C8
Microprocessor alert. After this warning,
cut off energy from the product and then
re-energize the product. If the same error is
displayed again, call an authorised service
agent.
A
B
ON/OFF
