EN - 18
Smart Pause
Smart Pause, when activated, reduces
the power of all burners that have been
switched on.
If you then deactivate the Smart Pause,
the heaters will automatically return to the
previous temperature level.
If the Smart Pause is not de-activated, the
cooktop will switch off after 30 minutes.
Press to activate Smart Pause. The
power for the activated heater(s) will reduce
to level 1 and “II” will appear at all displays.
Press again to deactivate Smart Pause.
“II” will disappear and the heaters will now
run at the level previously set.
Safety Switch-Off Function
A cooking zone will automatically switch off
if the heat setting has not been modified
for a specified duration of time. A change
in the heat setting of the cooking zone will
reset the time duration to the initial value.
This initial value depends on the selected
temperature level, as shown below.
Heat setting Safety switch off after
1-2 6 Hours
3-4 5 Hours
5 4 Hours
6-9 1.5 Hours
Child Lock
After switching on the appliance, the child
lock function can be activated. To activate
the child lock, simultaneously press the
left and right side of the Sliding Button
and then press the right side
of the Sliding Button again. “L”
indicating LOCKED will appear on all heater
displays and the controls can not be used.
(If a cooking zone is in the hot condition,
“L”and “H” will display alternately).
The hob will remain in a locked condition
until it is unlocked, even if the appliance
has been switched off and on.
To deactivate the child lock, first switch on
the hob. Simultaneously press the left and
right side of the Sliding Button
and then press the left side of the Sliding
Button again. “L” will no longer
be displayed and the hob will switch off.
Key Lock
The key lock function is used to set
‘safe mode’ on the appliance during
operation. It will not be possible to make
any adjustments by pressing the buttons
(for example heat settings). It will only be
possible to switch the appliance off.
The lock function is active if the key lock
button is pressed for at least 2 seconds.
This operation is acknowledged by a
buzzer. After successful operation, the key
lock indicator will flash and the heater will
be locked.
Timer Function
The timer function is available in two
versions, as follow.
Minute Minder Timer (1 - 99 min.)
The minute minder timer can be operated
if the cooking zones are switched off. The
timer display will show “00” with a blinking
dot.
Use the Timer and Sliding Button
to increase/decrease the time.
The range is between 0 and 99 minutes.
If there is no adjustment to the displayed
time within 10 seconds, the minute minder
timer will be set and the blinking dot will
disappear. Once the timer is set, it begins to
count down.
When the timer reaches zero, a signal will
sound and the timer display will blink. The
sound signal will stop automatically after 2
minutes and/or by pressing any button.
The minute minder timer can be changed or
switched off any time by using the Timer
and Sliding Button . Switching off
the hob by touching at any time will also
switch off the minute minder timer.
Cooking Zone Timer (1 - 99 min.)
When the hob is switched on, an
independent timer can be programmed for
each cooking zone.
Select a cooking zone, then select the
temperature setting and, finally, activate the
timer setting button , the timer can be
programmed to switch off a cooking zone.
Four LEDs are arranged around the timer
that indicate which cooking zone the timer
