EN - 17
Touch Control Unit
1- Key Lock Indicator
2- Heater selection
3- Timer display
4- Timer function cooking zone indicators
5- Timer selection
6- Key Lock
7- Smart Pause
8- Bridge heater selection
9- Sliding Buttons
10- Boost
11- On/Off
Use the induction cooking zones with
suitable cookware.
After mains voltage is applied, all displays
are illuminated briefly. After this, the hob is
in stand-by mode and ready for operation.
The hob is controlled by pressing the
appropriate electronic button. Each button
pressed is followed by a buzzer sound.
Switching the Appliance On
Switch the hob on by pressing the ON/OFF
button . All heater displays will show a
static “0” and the bottom right dots blink.
(If a cooking zone is not selected within 20
seconds, the hob will automatically switch
off).
Switching the Appliance Off
Switch the hob off at any time by pressing
.
The ON/OFF button always has priority
over the switch-off function.
Switching the Cooking Zones On
Press the heater selection button that
corresponds to the heater you wish to use.
A static dot will be shown on the selected
heater display and the blinking dots on
all other heater displays will no longer
illuminate.
For the selected heater, you can set the
heat level by pressing the Sliding Button
The element is now ready to
use. For fast boil times, select the desired
cooking level, then press the “P” button to
activate the Boost function.
Switching the Cooking Zones Off
Select the element you want to switch off
by pressing the heater selection key. Using
the Sliding Button , turn the
temperature down to “0”. (Pressing the right
and left of the slider button simultaneously
also turns the temperature to “0”).
If the cooking zone is hot, “H” will be
displayed instead of “0”.
Switching all Cooking Zones Off
To switch all the cooking zones off at once,
press the key.
In stand-by mode, a “H” will appear on all
cooking zones which are hot.
Residual Heat Indicator
The residual heat indicator indicates that
the glass ceramic area has a temperature
that is dangerous to touch.
After switching off the cooking zone, the
respective display will show “H” until the
corresponding cooking zone temperature is
at a safe level.
1
2
3 4
5
6 7 8
9
10 11
