Manual Text Booklet – Helix Plus Upgrade Kit – ENGLISH – 9

⚠

WARNING

⚠

Proper assembly is required. Check that leg connectors are properly installed and fasteners

are tight. Pull on leg connectors to confirm they are secure.

Attaching the stroller frame leg connectors

󱪼 Open one of the stroller frame leg connector

Ⓣassemblies by removing the two Phillips screws

that are loosely threaded into the connector using the included Phillips screwdriver tool. Position

each leg connector against its corresponding rear stroller frame leg, so that the triangular Helix

SmartHub Attachment openings are on the inside of the rear leg

Ⓢ. Slide the open leg connector

over the rear leg and around the tie rod bolt Ⓤ.

󱪼 Close the leg connector over the rear stroller frame leg. Using the Phillips screwdriver tool, fully

tighten the two mounting bolts to secure the connector in place. Check your installation by

twisting on the connector to ensure it does not move. Repeat with the other connector.

Attaching the stroller basket

󱪼 Insert the stroller basket handle

Ⓛ into the rail on the underside of the front SmartHub. You will

hear a CLICK when it locks in place.

󱪼 Expose the plastic handles

Ⓜthrough the opening in the basket fabric and then fix the front of the

stroller basket to the stroller frame by inserting the plastic handles one at a time into the openings

on the front part of the stroller frame.
