Hardware Installation Guide

OpenVox Communication Co. Limited. URL: www.openvox.cn 21/27

After system completed boot , enter I/O space based address 480H and change some register value

as follow:

LED6

1. Set 480H+28H, bit1 (bit7-----bit0)

2. the LED will light

3. clear the 480H+28H, bit1

4. the LED will dark

LED16

1. Set 480H+09H, bit1

2. the LED will light

3. clear the 480H+09H, bit1

4. the LED will dark

LED17

1. Set 480H+08H, bit1

2. the LED will light

3. clear the 480H+08H, bit1

4. the LED will dark

SW1

1. Set 480H+04H, bit6 ,means direction is input

2. press SW1 ,then 480H+08H ,bit6 will be changed to 0

3. when SW1 release, 480H+08H ,bit6 will be changed to 1 (default)

CN2.7-8pin GPIO

As output

1. clear 480H+04H, bit6 ,means direction is output

2. Set 480H+08H, bit6 ,CN2.7 will be changed to 1 (High level)

3. Clear 480H+08H, bit6 ,CN2.7 will be changed to 0 (low level)

As input

1. set 480H+04H, bit6 ,means direction is input

2. CN2.7 input 1 (High level), then 480H+08H, bit6 will be changed to 1

3. CN2.7 input 0 (Low level), then 480H+08H, bit6 will be changed to 0

BIOS Setup Guide

1. Enter BIOS setup menu

When system is powered up, press F4 on keyboard of remote PC connected IPC110’s serial port.
