18 User Manual Refrigerator
Securing the Upper Fixing Plate:
Attach the upper fixing plate of the drawer to the cabinet door:
Tighten the hexagonal flange nut onto the upper fixing plate.
(Refer to Fig. 18)
Securing the Refrigerator Door Body:
Tighten the base screws and the hexagonal socket set screws
located on the side of the refrigerator door body:
(Refer to Fig. 19)
Installing Refrigerator Accessories
Attach the refrigerator trim covers:
Insert the top and bottom trim covers into their respective caps
on the refrigerator. (Refer to Fig. 20 & 21)
Installing Your Refrigerator
Figure 18
Hexagon Flange Nuts
Figure 20
Hex Socket
Set Screw
Set Screw
Allen Key
Figure 20
Upper Decorative Cover
Figure 21
Lower Decorative Cover
