16User Manual OFOGC9010X
Testing Appliance Operation
After installation, test the appliance and ensure that it operates
correctly before handing it over to the customer. The following
procedure is recommended:
• Begin by turning on the gas and electricity supply, then attempt
to ignite all of the burners, both separately and in combination.
Note that additional time may need to be allowed for the initial
lighting, as air has to be purged from the pipes.
• Observe the flame appearance on each burner, shown in
the diagram above. If it is much larger or much smaller than
expected, the injector size and supply pressure require
checking. Where a flame is unsatisfactory, refer to the
troubleshooting guide to correct the fault. If the troubleshooting
guide does not solve the problem, please call our friendly After
Sales Support Team.
• When all the foregoing is satisfactory, check the turn down
(minimum or low) setting on each burner, as this may need
adjustment. Valves have a bypass controlling screw, which may
be accessed by removing the knob, as shown in the diagram to
the right. This screw will be located on a particular area of the
valve. Normally, this will have been correctly set at the factory for
use on natural gas (NG) and should not require adjustment.
•
IMPORTANT: If the appliance has been converted to LPG, then
the bypass screw will HAVE to be screwed in until a small, stable
flame results.
•
IMPORTANT: ensure the supply pressure has been checked
PRIOR to any adjustment.
If the cooktop’s flame cannot be adjusted to perform safely inform
the customer of the problem and affix an appropriate warning
notice to the appliance.If the fault appears to be dangerous the
appliance should be disconnected. If a minor fault exists, the
customer may wish to use the appliance while awaiting service.
If a fault cannot be fixed, please call the our friendly After Sales
Support Team at 1300 11 4357.
The customer should be advised that, in the event of a fault, the
local service organisation or the retailer from whom the appliance
was purchased should be contacted.
When satisfied that the unit is operating correctly, turn off and
instruct the customer on correct operation as outlined in this
booklet. Ask the customer to operate the controls to ensure that
the correct procedure is understood.
CAUTION: Servicing must only be carried out by an authorised
service technician.
Injector sizes required for various gas types are shown in the tables
on page 15 and the Technical Specifications chapter found on
page 21, and may depend on your model. The appliance test point
pressure for each gas type is also shown.
For model identification after installation, an additional rating label
sticker has been provided. This sticker is to be stuck onto adjacent
cabinetry.
Examples of
Bypass Screws
Maximum adjustment to flame height ↓
Minimum adjustment to flame height ↓
Installing Your Freestanding Cooker (Continued)
