7.3 Additional functionalities

REMOTE ENABLE

It allows to activate/deactivate the unit from remote when the CTRL-DSP is not used (e.g. in case of ModBus). To enable this

functionality,connecttheHY/S1input(Fig.5q)removingthebridge.Withopencontact,DISABLEDushesontheLCD(Fig.7b

- ).

BYPASS

The SITALI units are equipped with a physical bypass which allows to mitigate the heat exchange when the indoor and outdoor

temperature combinations are such that the heat exchange is not recommended. If activated the Bypass icon is displayed.

(Fig. 7b).

ANTI-FROST

Intake fan speed is reduced during very cold weather in order to prevent ice inside the unit which could damage the heat

exchanger.Ifactivated,theANTI-FROSTiconisdisplayed(Fig.7b).

ERRORS WARNING DISPLAYED ON THE CTRL-DSP

Code error description (Fig. 7b - )

E000 no RS485 connection between the CTRL-DSP and the motherboard

E001 no rotation of the exhaust air fan (Fig. 8.a - )

E002 no rotation of the intake air fan (Fig. 8.a - )

E003 thermistor T11 broken/disconnected (Fig. 7.a)

E004 thermistor T12 broken/disconnected (Fig. 7.a)

E005 thermistor T21 broken/disconnected (Fig. 7.a)

E006 thermistor T22 broken/disconnected (Fig. 7.a)

E007 alarm BST input

E008 CTRL-DSP internal error

NOTE:ifCTRL-DSPisabsent(orfaulty),theunitoperatesinthepreviouslysetmode.

TheWeeklyTimer,NightModeandFilterAlarmfunctionalitiesdonotwork.

It allows to set the LCD contrast.

Press OK to enter.

Increase/decrease the contrast using  or .

Press OK to conﬁrm.

Installer Menu

21 Load Settings

22 Restore Default Settings

23 Contrast

24 Debug page

It shows the internal functional parameters of the unit.
