To be selected only in case an external heating element (not supplied with the unit) is used.

Press OK to enter.

“1 Heater”

Press OK to enter.

ChooseNO/PRE/POSTusing or .

Press OK to select.

Factorysetting(DEFAULT):NO.

If“NO”:theHEAToutput(Fig.5g)isneveractivated.

If“PRE”:theheaterisinstalledtothe“intakeairside-T21”(Fig.7.a)andtheHEAToutput

(Fig. 5g) is activated.

“2HeatingthresholdPRE”:

it allows to set the heating threshold.

Thesettingrangeis:-20°C÷+10°C.

Increase/decrease the temperature using  or .

Press OK to select.

Factorysetting(DEFAULT):0°C.

If the heater is activated, the icon is displayed.

If“POST”:theheaterisinstalledtothe“supplyairsideT22”or“extractairsideT11”(Fig.7a);

use the submenu “4 POST Temperature input” to select the side. The HEAT output (Fig. 5g)

is activated.

“3HeatingthresholdPOST”:

it allows to set the heating threshold.

Thesettingrangeis:+15°C÷+25°C.

Increase/decrease the temperature using  or .

Press OK to select.

Factorysetting(DEFAULT):+20°C.

If the heater is activated, the icon is displayed.

Installer Menu

8 Heating

10 Speed setting

11 Airow Balancing

12 F7 lter

13 Filter Alarm interval

ItallowstoadjustthespeedsinNormalMode3V,BoostorHoliday.

Press OK to enter.

Choose speed 1, speed 2, speed 3, Boost or Holiday using  or .

Press OK to select.

Thesettingrangesare:

Speed1:10%÷80%.Factorysetting(DEFAULT):40%.

Speed2:20%÷90%.Factorysetting(DEFAULT):60%.

Speed3:30%÷100%.Factorysetting(DEFAULT):80%.

Boost:Speed3÷100%.Factorysetting(DEFAULT):100%.

Holiday:10%÷40%.Factorysetting(DEFAULT):20%.

Increase/decrease the speed using  or .

Press OK to select.

Press ESC to go back to the previous menu.

Installer Menu

8 Heating

10 Speed setting

11 Airow Balancing

12 F7 lter

13 Filter Alarm interval
