5.4 Precabled electric connections

The unit must be earthed.

Theunitiswiredinternallyfromfactory.

Unitcomespre-wiredwith:

-powersupplycable(3-core:brown,blue,yellow/green).

-controlcable,forconnectiontoCTRL-V1supplied(6-core:brown,yellow,white,green,grey,pink).

Factorysetting:speed1at40%,speed2at70%andspeed3at100%.

WARNING

Makesurethatthemainssupplytotheunitisdisconnectedbeforeperforminganyinstallation,service,maintenanceor

electrical work!

WARNING

Theinstallationandserviceoftheunitandcompleteventilationsystemmustbeperformedbyanauthorizedinstallerandin

accordance with local rules and regulations.

Fig. 5.e Precabling

Fig. 5.f CTRL-V1

(supplied as standard)

GREEN

WHITE

GREY

YELLOW

POWER

SUPPLY

BLUE

YELLOW-GREEN

CONTROL

PINK

BROWN

+12V

Alm

GND

Scom

CTRL-V1

BROWN
