EN - 40

ENGLISH

1.5 - PRODUCT RANGE

The there are two basic types of Bi2 cooler-radiators/cooler-convectors, SL and

SLR, each of which is o󰀨ered in ve sizes with di󰀨erent performances and

dimensions.

SL

cooler-convector (suitable for horizontal or vertical installations).

SLR

ventil radiator with radiant plate (suitable for vertical installations).

1.6 - MORE ABOUT THE Bi2 (Fig.1)

A . Supporting structure

in high resistance electro-galvanised steel sheet.

B. Cold water heat exchange battery

  incopperpipesandaluminiumnswithhighe󰀩ciencyturbulence.eurokonus¾typethreadedunions

incompliancewiththenewEuropeancommunitystandardisationrequirements.

  Thebatteryisequippedwithaspecialsensorfordetectingthewatertemperature(SLandSLRversion).

C. Heating plate;

  highe󰀩ciencyandconnectedtothehotwaterbattery(SLRversion).

  Thehydraulicunitisttedwithacalostatvalvethatpreventscoldwaterfromenteringtheplate.

D. Ventilating unit consisting

ofatangentialfanwithunphasedbladesinsyntheticmaterial(extremely

quiet)mountedonanti-vibrationsupportsinEPDM,balancedstaticallyanddynamically,andsplined

directly onto the motor shaft.

E . Low consumption DC brushless electric motor

resin-coated coil mounted on anti-vibration supports in EPDM.

F . Reversible air outlet grill painted

  withepoxypowderpaintandoven-dried.Itslargesizeensureshighmechanicalresistance..

G. condensation collection

  basinforverticalinstallation,madefromABSandeasytoremoveforcleaning.Forhorizontalinstal-

lationoftheSLversions,ahorizontalcondensationcollectionbasinaccessorykitisavailable.

H. Structural back-plate

,

anti-condensation and high resistance.

I. Detachable front casing

and side plates.
