Je bekijkt pagina 4 van 23
MCTRL R5 LED Display Controller User Manual
www.novastar.tech
1
1 Overview
Introduction
The MCTRL R5 is the first LED display controller of NovaStar that supports image rotation. A single MCTRL
R5 features a load capacity of up to 3840×1080@60Hz. It supports any custom resolutions within this
capacity, meeting the on-site configuration requirements of ultra-long or ultra-wide LED displays.
Working with the A8s or A10s Plus receiving card, the MCTRL R5 allows for free screen configuration and
image rotation at any angle in SmartLCT, presenting a variety of images and bringing an amazing visual
experience to users.
The MCTRL R5 is stable, reliable and powerful, dedicated to providing an ultimate visual experience. It can be
mainly used in the rental and fixed installation applications, such as concerts, live events, security monitoring
centers, Olympic Games and various sports centers.
Features
A variety of input connectors
− 1x 6G-SDI
− 1 × HDMI 1.4
− 1x DL-DVI
8x Gigabit Ethernet outputs and 2x optical
outputs
Image rotation at any angle
Work with the A8s or A10s Plus receiving
card and SmartLCT to support image
rotation at any angle.
Support for 8-bit and 10-bit video sources
Pixel level brightness and chroma
calibration
Working with NovaLCT and NovaCLB, the
receiving card supports brightness and
chroma calibration on each LED, which
can effectively remove color discrepancies
and greatly improve LED display
brightness and chroma consistency,
allowing for better image quality.
Firmware update via USB port on the front
panel
Up to 8 devices can be cascaded.
Table 1-1 Feature constraints
Feature
Constraints
rotation
A 10-bit input does not support image rotation.
The screen must be configured on the MCTRL R5 before rotation setting in the LCD menu.
The screen must be configured in SmartLCT before rotation setting in SmartLCT.
