H Series Video Wall Splicers User Manual
www.novastar.tech
3
Control Card
You can control the H series devices on a control PC through either of the following two methods.
Method I: Direct control for single-user control
Connect the device Ethernet port to the control PC.
Method II: Using a router or switch, for multiple user collaboration in a wired or wireless way
Connect the Ethernet ports of both the device and control PC to the router or switch.
Figure 1-4 Control card connection
Preview Card
The H series allows you to monitor the inputs and outputs on a PC or monitor.
Figure 1-5 Preview card connection
Via Ethernet port:
Connect one of the Ethernet ports on the preview card and the Ethernet port of the control card to the
same switch for the input source and screen monitoring on the Web page.
Via HDMI connector:
Connect the HDMI connector of the preview card to a monitor for on-site monitoring.
