7. PRO G R A M | 43
setting to On, on the first page of the AUX KB menu (Shift+Program 4).
Page 2 of the Aux KB menu lets you assign which Layers should be part
of the Aux KB configuration and be played by incoming MIDI rather than
by the internal keyboard. Focus the Organ, Piano or Synth sections,
using the 1-3 soft buttons, and use the dial to select the appropriate
Layers for each section.
When a Layer is in Aux KB mode its Aux KB LED, below the Layer fader,
is lit to indicate that it is not controlled by the internal keyboard.
i The MIDI Channel for the Aux KB feature is set in the MIDI Menu on
the Nord Stage 4. Read more on this on page 59.
ABOUT PEDALS AND OTHER DEVICES IN AUX KB MODE
The Nord Stage 4 pitch stick, and sustain pedal will affect the selected
sound engine according to how the respective panel controls are set.
If SUSTPED and PSTICK are turned off on the panel, these are only
controlled by incoming MIDI on the Aux KB channel.
i A Swell pedal connected to the Nord Stage 4 also affects an
externally played Organ in Aux KB mode.
SHIFT / EXIT BUTTONS
Many buttons, as well as a few of the knobs, have a
secondary function which is accessed by holding SHIFT
and pressing the button or turning the knob. Shift activated
functions are always printed below the corresponding control.
For example, holding Shift and pressing the Program 7
button will open up the MIDI Menu.
There are two Shift buttons on the Nord Stage 4 with the same
functionality; one located at the bottom right of the Program area and
one conveniently placed on the left side of the Layer Effects Section.
Shift is also used as an EXIT function for menus, and for cancelling Store
operations.
HOLD TO SHIFT FUNCTION
Most Shift functions on the panel can also be activated
by pressing down the corresponding button for a short
while. This functionality is indicated by a non-filled arrow
( )next to the button text.
LIVE MODE
The Nord Stage 4 has eight easy-to-access Live
program locations, differing from other programs in that
any edits to them are automatically stored. When leaving
a Live program or powering off the machine all edits are
saved, without the need for a manual Store operation.
To select a Live Program, press LIVE MODE and then any of the 1-8
buttons in the Program area.
The selected Live program can be stored to a program bank location,
using the standard Store methods (see previous page for details).
Conversely, a regular program can also be stored to a Live program
location if desired. Pressing Shift+Live Mode activates the Numeric Pad
(NUM PAD) navigation mode, read more about this below.
PROGRAM BUTTONS
The eight PROGRAM buttons give you immediate access to a range of
eight programs – corresponding to a Page – within the current program
Bank. Program buttons 1-4 (the top row) are also used as soft buttons
when operating menu settings. Read more about soft button
functionality on page 56.
NUM PAD (NUMERIC PAD)
There are two distinct options for how programs and banks are
navigated: The default “page based” mode and the Numeric Pad mode,
activated by pressing NUM PAD (Shift+Live Mode).
In Numeric Pad mode the Program 1-8 buttons are used for entering
any program number (11-88) within the current bank, rather than directly
switching between the 8 programs on a page.
As an example, to select program 12 within the current bank, first press
Program button 1 (to select page 1) and then Program button 2 (to
select program 2 within that page). Here are some additional points:
• The PAGE/BANK buttons and the Program dial work the same
regardless of mode.
• LIVE MODE programs are always directly selected using the 1-8
Program buttons.
MENUS
The PROGRAM 1-8 buttons are also used for accessing the menus or
the Organize mode, when used in conjunction with the SHIFT button.
Menu settings are described in the Menu chapter beginning on page
56. Organize is described in the following section.
Pearl Upright L
Melody Pad
2:53
B3 Flute 2
1:27
Sweet Layers
E:1-
In this example, the Program 1 button has been pressed. The dash (-)
indicates that another digit can be entered, to select program A:11-18.
