3. GETTING STARTED | 13
3 Try selecting a piano sound from the LIST view, accessed by
pressing SHIFT and turning the PIANO SELECT dial. Use Shift again
to EXIT the list view.
Note that changing any parameter on the Nord Stage 4 panel causes
an “E” to appear next to the current program number in the display.
This indicates that the program has been edited but not yet saved
into memory. If a new program is selected prior to performing a Store
operation any edits will be lost and the program will have its original
settings the next time it is loaded.
TURN OFF MEMORY PROTECTION
When the Nord Stage 4 is shipped from factory its memory is protected
to prevent accidental overwriting of original programs. Memory
protection can be turned off by toggling a setting located in the System
menu.
1 Hold SHIFT and press the SYSTEM (Program 1) button below the
display.
2 Memory Protection is the first setting of the System menu. If the
display shows a different setting, use the Page3button to navigate
to the Memory Protection setting.
3 Change this setting to Off by turning the PROGRAM dial.
4 Press EXIT (Shift button) to exit the System menu.
i This setting, like all other System settings, will be permanently
stored until it is changed again.
Read more about menu settings, starting on page 56.
STORE A PROGRAM
1 Press the STORE button to the left of the display once, to begin the
process of storing the current program.
2 The STORE LED will begin to flash and the display will ask you for
the location to where you want to store the program.
i Some Programs, such as A:21 White Grand in this example, are
named after a specific sound in the Piano section. Note that this
name does not change if you store the Program with a different
Piano selected, but needs to be manually set through a Store As
operation, or by using the Nord Sound Manager
3 If you want to store the edited version to the current location,
replacing the original, simply press STORE again. If not, use the dial
and/or PAGE 3/4 buttons to select a different location.
l The program in the selected location becomes active on the
keyboard, allowing it to be auditioned before it is replaced by the
program being stored.
4 When you have found a suitable location for your program, press
STORE again to confirm the store operation.
i Press Shift/Exit once to abort an ongoing Store process if you
change your mind.
Read more about Store and how to name a program in the Program
chapter, on page 39.
LIVE MODE
The eight LIVE programs differ from other programs in
that all edits made to them are instantly stored – without
the need for a manual Store operation.
1 Press LIVE MODE and use the PROGRAM buttons to navigate the
eight Live programs.
2 Make an edit, such as activating one of the effects sections, to one
of the programs.
3 Select a different Live program and then return to the one that was
edited. Note that the edit was automatically stored.
If Live Mode is active and you decide to store the settings permanently
as a program in one of the Program banks, you can do so using the
standard Store methods (see above).
You can also store programs into any of the eight Live Mode memory
locations, in which case the program settings will replace that current
Live Mode memory setting.
Press the Live Mode button again to exit Live Mode and return to the
Program banks.
i When the Nord Stage 4 is shipped the eight Live Mode Programs
are simply copies of the first eight Programs in Bank A of the
Program banks.
SECTIONS AND LAYERS
A Section on the Nord Stage 4 refers to the ORGAN, PIANO and SYNTH
areas of the panel respectively, including their individual Layers. The
Organ and Piano Sections contain two Layers each, labeled A and B,
while the Synth Section contains three Layers; A, B and C.
Entire Sections can be turned On or Off by pressing the Section ON
button.
STORE PROGRAM TO
A:21
White Grand
A:21
White Grand
EP3 Shallow Close L
E
