16 | NORD ORGAN 3 USER MANUAL OS V1.0X
FARF REGISTERS
The labels used for the FARF drawbars/registers are printed on the
upper row, above the drawbar LEDs or drawbars.
The drawbars act as on/off switches, or “register selectors” when the
Farf model is selected. Instead of drawbars, the original instrument used
rocker switches for selecting instrument voices (in reality different filter
settings) in various footage (octave) ranges. Drawbar LEDs 5-8 are lit up
for an activated voice, and drawbar LEDs 1-4 are lit up for a deactivated
voice. Pulling a drawbar more than half way out will activate that register.
The table below shows the original register name:
Drawbar Voice Panel Name
1 Bass 16 BASS16
2 Strings 16 STR16
3 Flute 8 FLUTE8
4 Oboe 8 OBOE8
5 Trumpet 8 TRMP8
6 Strings 8 STR8
7 Flute 4 FLUTE4
8 Strings 4 STR4
9 A bright voice, an octave
and a fifth above the
fundamental
2 2/3
The illustration below shows the pitch interval between each voice when
the key of C3 is played. Though some voices have the same pitch, they
differ in tonal character.
VIBRATO
The original instrument has two basic vibrato modes; “Light” and
“Heavy”, with different rates for each mode. There are several types of
vibrato and choruses available for the Farf model on the Nord Organ 3.
The V1, V2 and the C3 settings are the ones that are modeled after the
original instrument. Like with the Vox, the Farf vibrato is shared by the
Upper and Lower manuals, with their respective controls always being
changed in tandem.
SOFT B3
For scenarios where a B3-like sound is desired, but without the
keyboard click and other artifacts, the SOFT B3 is an appropriate choice.
The drawbars correspond exactly to those of the B3 model.
With the Soft B3 selected, the B3 Key Click parameter, as well as B3
Percussion have no effect on the sound.
PIPE ORGAN
The PIPE organ model faithfully recreates a principal pipe section – the
sets of metal pipes, or ranks, that commonly make up the backbone of
a pipe or church organ. While other ranks may attempt to recreate the
sounds of other instruments (flutes, trumpets, strings etc.) the principal
sound is non-imitative and unique to the pipe organ.
The pipe lengths available for the Pipe models correspond to those of
the B3 model, ranging from 16 feet to 1 foot.
PIPE VIBRATO/CHORUS
Activating VIBRATO/CHORUS for the Pipe organ switches to a model
which is tuned with less precision. This produces chorus-like effects,
slight dissonances and adds realism when combining registers.
BASS MODELS
For each of the Organ Models there is a
corresponding Bass Model, used for the Pedal Bass
drawbars. It is not necessary, however, to pair the
Organ Model with its exact counterpart, but Organ
and Bass combinations can be chosen freely among
the available selections.
Activating ALTERNATE (Shift+Bass Model) selects an
alternate model for the current position. The alternate
for each Bass Model is decribed further below.
Four of the Bass Models – B3, FARF, PIPE and SOFT (alternate setting
for Pipe) – are polyphonic, meaning that multiple notes can be played
at once. The remaining Bass Models – TRK, VX and USER – are
monophonic, allowing one note to be played at a time.
i With the Sustain control turned on at any of its 1-3 settings, all
bass models and their alternate settings are monophonic.
B3
On the Nord Organ 3, the B3 BASS model features a common and
popular modification whereby certain partials are removed from the 8
foot drawbar. This 8’ sound, especially when combined with the 16’
drawbar is often perceived as more solid and less reedy than without the
modification applied.
B3 ALTERNATE
The alternate setting for the B3 bass model provides the full, non-
modified sound of the 8’ drawbar.
C3
