10 | NORD ORGAN 3 USER MANUAL OS V1.0X
MASTER LEVEL
The Master Level knob sets the overall output level of
the instrument. Unlike most other panel controls, its
value is not stored with individual programs but will
always have the level to which it is physically set.
SOFT BUTTONS
Certain menu settings or actions are accessed using so called “soft
buttons”. Soft buttons are positioned in the display in relation to the
buttons surrounding it, and are controlled with the PROG and LIVE 1-3
buttons.
PROGRAMS
The Program area is located at the center of the panel, with the OLED
display in the middle. A program contains complete settings for every
parameter on the panel and is stored in the program memory of the
Nord Organ 3, with enough room for 400 programs.
Programs are organized into 8 banks, labeled A-H. All programs can be
edited and replaced as desired.
i A complete set of the factory programs is available from
nordkeyboards.com. This means that the program memory can
always be restored to its original state.
SELECT A PROGRAM
Programs are selected by turning the PROGRAM dial or by pressing the
PROG/PAGE 3/4buttons, which will navigate between programs in a
stepwise fashion.
i The Page functionality of the Prog/Page buttons relates to how
these buttons are used when the System or Sound menu is open,
for navigating between menu pages.
A Program Bank on the Nord Organ 3 contains 50 program locations.
Press BANK 3/4(Shift+Prog/Page) to switch between different banks.
LIST VIEW
Programs can also be viewed and browsed in a useful list view:
1 Press SHIFT and turn the PROGRAM dial to enter a list view of all
the Programs.
2 Browse to any program, using the PROGRAM dial. All 8 program
banks can be accessed when in List mode.
3 Press SHIFT again to EXIT the List view.
PROG MODE (PROGRAM MODE)
The important PROG MODE button determines the
behaviour of the LED equipped drawbars. When Prog
Mode is lit, Program Mode is active and the LED
equipped drawbars are using the drawbar settings that
belong to the currently loaded program. The setting for
each drawbar is in this case indicated with a single LED.
When Prog Mode is off, Panel Mode is active in which
case the drawbar LEDs are unlit and the physical positions of all
drawbars are used.
A number of other panel functions are also individual for the Panel and
Program modes respectively. These include:
• B3 CLICK
• VIBRATO/CHORUS
• TO LOW MANUAL and FX BYPASS settings for the Bass Pedals
• SUSTAIN for the Bass Pedals
• B3 PERCUSSION
The Prog Mode setting is stored per program, meaning that some
programs can be loaded using drawbar settings appropriate for that
specific program, while others maintain the physical drawbar positions.
l The Panel Mode setting is useful for maintaining a “manual” organ
that persists between program changes, meaning that you can
keep all the drawbar and other settings listed above as you last
left them, while loading a different program using other settings for
the Rotary Speaker, Effects, and anything else that is stored with a
program.
THE “NORD B3” PROGRAM
When shipped, the Nord Organ 3 is set to start up with the special
“Nord B3” program selected. This program functions differently from
other programs in a couple of important ways:
• This program, regardless of edits made to it, will always load with the
B3 Organ and Bass models selected, and in Panel Mode (meaning
that physical positions of drawbars are used), with the Rotary Speaker
set to its default values.
• Its program location can not be stored to, meaning that the program is
“read only” and can not be overwritten.
This program is intended as a suitable starting point for instruments that
may be used by multiple musicians, and where edits made by a previous
user should not persist after the instrument has been turned off.
l If desired, the setting for booting to the Nord B3 program can be
turned Off, in which case the instrument will start up to the program
that was selected when the instrument was last turned off. This
is done on the first page of the SYSTEM menu (Shift+Live 1). See
page 28 for more details.
A:01 B3 Panel
A:02 B3 Jazz
A:03 B3 Gospel 1
A:04 Vx Machine
A:05 B3 Gospel 2
A:06 Principal Pipe
B3 Panel
A:01
