5. The Editor application: Modulation NORD MODULAR G2 V1.4x
Page 76
like ConstSwM. When there is no arrow the Name button will toggle between
ON
and
OFF
when repeatedly
pressing the name button.
MODULATION
The method of controlling one function in a module with another function is named to modulate. When
you play on a keyboard and the oscillator changes its pitch when you wiggle the Pitchstick controller, you
are manually modulating the pitch with the Pitchstick. Modulating can be done automatically (as opposed
to manually) by means of varying control signals. A good example is when an envelope sweeps a filter
when a key is pressed. Logic signals from the keys tell the envelope to start modulating the cut-off
frequency of the filter. Modulation can be positive or negative, e.g. the cut-off frequency of a filter can
increase with positive modulation and decrease with negative modulation or vice versa. As you will see,
there are some modules in Nord Modular G2 that can change the polarity of a modulator signal. Some
modules can be set to send either bipolar or unipolar control signals, like the Envelope, LFO and
Constant modules or the Control Sequencer module.
M
ODULATION
INPUTS
A module parameter that can be modulated through a control
signal must have a modulation input where the control signal can
be connected to. A modulation input is often combined with a
modulation amount knob. For short a modulation input is named
a mod-input. The modulation amount knob attenuates the
incoming signal to the wanted modulation depth. The mod-
inputs can be red, like the Sync, FM and Shape inputs of the
OscillatorB module, which means they are capable of handling
signals at full audio bandwidth. Alternatively mod-inputs can be
blue, like the Vowel modulation input of the Voice Filter module, working at 1/4 audio bandwidth. The
modulation inputs can also be self-optimizing, like the Pitch inputs of the Oscillator B module, meaning
that they adapt their bandwidth to the incoming modulation signal bandwidth. This is indicated by the
inputs changing color.
