NORD MODULAR G2 V1.4x 4. The G2 Editor software: The Editor software
Page 55
4. THE G2 EDITOR SOFTWARE
THE EDITOR SOFTWARE
On the CD-ROM that comes in the back of this manual you will find the G2 Editor software for
Windows and Macintosh OSX computers. This software opens up the full potential of the G2 system.
With this software you can manage the Patch and Performance memory banks, control all System,
Performance and Patch functions and last but not least create your own synthesizer and audio Effects models as
Patches and combine them into Performances ready to be recalled and played from the G2 system Patch
and Performance memory banks.
S
OFTWARE
INSTALLATION
N
OTE
! B
ASIC
COMPUTER
SPECIFICATIONS
ARE
FOR
EDITING
ONE
G2.
E
DITOR
SYSTEM
REQUIREMENTS
W
INDOWS
PC
The Nord Modular G2 Editor software requires a Pentium II PC running at 500 MHz or better with
minimum 64 MB RAM for Windows 98SE, or a Pentium II PC running at 500 MHz or better with
minimum 128 MB for Windows2000 and XP. Additionally a free
USB
(1.1) port plus a CD ROM drive
to install the software from CD, a keyboard, a mouse and a graphics display with an on-screen resolution
of 1024 by 768 pixels and a 16-bit color or better graphics adaptor.
The computer has nothing to do with the actual sound processing in the Nord Modular G2 - it is used
only for visual Patching and to send instructions to the Nord Modular G2. Note that a PC with lower
specifications could be used without affecting the G2 synthesis capabilities, but graphics might be dead
slow and the PC might not be able to sustain the high
USB
data rate between the PC and the G2.
E
DITOR
SYSTEM
REQUIREMENTS
M
ACINTOSH
The Nord Modular G2 Editor software requires as a minimum a Macintosh G3, 400 MHz,
USB
-port, 128
MB RAM and OSX 10.2 or later.
W
INDOWS
98SE/2000/XP, A
PPLE
M
AC
OSX
It is beyond the scope of this manual to explain the functions of these operating systems. In order to run
the Editor, you need to be familiar with the basic functions of the computer, like mouse functions, saving
and loading files to and from disk drives, moving and closing windows, closing dialog boxes etc. It is also
important that the computer has a free
USB
port. On a Windows PC the Nord Modular G2
USB
driver
must have been properly installed before connecting the Nord Modular G2 synth to the PC.
W
HEN
EDITING
MORE
THAN
ONE
G2
The G2 V1.4x Editor software supports up to four G2 units to be connected to the computer. The
system requirements in the previous paragraphs are for editing a single G2. To edit more than one G2
you might want to use a computer that is about twice, three times or four times the specifications of the
ones described, to prevent the screen graphics to appear slower. A currently ‘state of the art’ computer,
like a Pentium IV running at 2GHz or faster, will easily be able to edit four G2’s and still have fast graphic
screen refreshing for all the
LED
s on the modules in a patch.
