3. Working with the synth: Nord Modular G2 rear panel NORD MODULAR G2 V1.4x
Page 54
S
USTAIN
P
EDAL
(G2, G2X)
Connect a sustain pedal to the S
USTAIN
P
EDAL
input. The polarity of the input can be adjusted to suit
different types of Sustain Pedals.
USB C
ONNECTOR
The
USB
(1.1) connector is used to connect the G2 to a computer. Connect a free
USB
port of the
computer that runs the Editor software to the
USB
Port. The
USB
connection is hot-pluggable.
MIDI I
N
, MIDI O
UT
AND
MIDI T
HRU
C
ONNECTOR
Connect any external
MIDI
equipment to the
MIDI
IN
,
MIDI
OUT
and
MIDI
THRU
ports. This could be
a sequencer, a master keyboard or another
MIDI
device.
A
UDIO
O
UTPUTS
The unbalanced, line level (-10 dBV) audio outputs O
UTPUT
1-4 route the audio signals from the four
virtual mix buses in Nord Modular G2. Use O
UTPUT
1 if you are going to use Nord Modular G2 with a
mono sound system. If only O
UTPUT
1 is connected, the audio from O
UTPUT
2 is mixed to O
UTPUT
1.
A
UDIO
I
NPUTS
By connecting external sound sources to the unbalanced, line level (-10 dBV) inputs I
NPUT
1-4, you can
feed audio signals into the G2 and process the audio with any of the available G2 modules.
H
EADPHONES
O
UTPUT
The H
EADPHONES
output routes audio signals which are assigned O
UTPUT
1 and 2.
Note! Since the G2 Engine lacks a volume knob, be careful when you use headphones so the
volume isn’t too loud. Make it a habit of always lowering the Patch Level in the Editor before
using headphones with the G2 Engine.
XLR M
ICROPHONE
I
NPUT
(G2, G2X)
The
XLR
M
IC
INPUT
can be used for dynamic, non-Phantom powered microphones. If you use the
I
NPUT
1, it will automatically override and disable the M
IC
INPUT
. So, if you want to use a microphone
be sure no jack plug is connected to the I
NPUT
1. The M
IC
INPUT
has a built-in preamp so you don’t have
to amplify the signal externally to use a dynamic microphone on this input. The G2X model comes with
a goose-neck microphone that can be readily plugged into the
XLR
connector.
G2 E
NGINE
REAR
PANEL
Note! The Control Pedal input, the Sustain Pedal input and the XLR Microphone input are not available
on the G2 Engine model.
