3. Working with the synth: Editing Patch Settings NORD MODULAR G2 V1.4x
Page 34
EDITING PATCH SETTINGS
Press the P
ATCH
S
ETTINGS
button to the top right of the panel so the button
LED
lights up. This mode
displays basic Patch settings for the Patch. The parameter names are printed on the panel above each
A
SSIGNABLE
D
ISPLAY
and you can edit them by turning the A
SSIGNABLE
K
NOBS
and/or the
A
SSIGNABLE
B
UTTONS
.
You can revert back to Patch Edit mode by pressing the P
ATCH
button again so the button
LED
dims.
M
ASTER
C
LOCK
Set the Master Clock Rate with the corresponding Knob. Run/Stop the Master Clock with the
corresponding Button below the Knob.
The Master Clock can control several different functions:
4. It can be the
MASTER
MIDI
CLOCK
for your whole
MIDI
setup
5. It controls the Arpeggiator Speed
6. Several LFO modules can be controlled directly by the Master Clock
7. The Delay-time of some Echo Delay modules can be synced to the Master Clock
8. When several Slots are active they can all sync to and follow the current Master Clock rate, as the
Master Clock is global to the whole G2 system.
9. When the Master Clock is the
MIDI
MASTER
CLOCK
in your setup, the Run/Stop button will send out
MIDI
START
and
MIDI
STOP
commands over the
MIDI
OUT
connector. Note that the G2 system must
be set in the System menu to send
MIDI
CLOCK
commands over the
MIDI
OUT
connector to use the
G2 system for the
MIDI
MASTER
CLOCK
in your setup.
Sending
MIDI
CC
#80 on the Global
MIDI
channel will also start/stop the Master Clock. This feature
is particularly useful when a G2 E
NGINE
model is controlled by an external
MIDI
controller device.
10. If the G2 is set to receive
MIDI
CLOCK
commands and a
MIDI
CLOCK
signal is present on the
MIDI
IN
connector, this external
MIDI
CLOCK
will automatically take over and start to be the Master Clock.
The Arpeggiator, the LFO’s and the Delay modules set to Clk mode will now sync automatically to
the external
MIDI
CLOCK
. The average tempo of the external
MIDI
CLOCK
will be displayed in the
panel display and the endless knob that normally sets the tempo will become inactive.
Note that an
EXTERNAL
MIDI
CLOCK
signal must be stable and ‘jitter free’ for reliable control of the
delay time on delay modules.
V
OICE
M
ODE
Set requested polyphony with the Knob (2-32 voices). The actual polyphony is displayed together with
the requested polyphony within parenthesis. Actual polyphony depends on the complexity of the loaded
Patches and how many Slots are loaded and active (Slot
LED
s light up).
1:1 Bass
120 BPM 14 (16)
Stop Poly
1/16 Rnd
Off 1 Oct
50 cnt 1.0 s
Off Off
2 semi -7.3 dB
On MuteOff
