NORD MODULAR G2 V1.4x 13. Module reference: Level group
Page 233
M
OD
A
MT
The Modulation amount control module can be used to
change the characteristics of a control signal before
being routed to a control signal input of a module.
M
/1-
M
Click the m/1-m button to output the signal patched to the input at full level when the Mod depth knob
is at its minimum value. If the 1-m function is inactive, the signal patched to the input won’t be output
at all at minimum Mod depth value (see example below).
M
OD
INPUT
Patch the control signal you want to multiply with the input signal here (see example below). See also
"Common Level module parameters”.
E
XAMPLE
Let’s say we want to modulate the amplitude of an LFO signal with an Envelope control signal and be
able to control the total output level of the resulting signal with the Mod depth knob.
Mod depth: 50%
Mod depth: 100%
Mod depth: 0
m:
1-m:
Env signal on
Mod input
LFO signal
on input
INPUT SIGNALS: OUTPUT SIGNALS:
