NORD MODULAR G2 V1.4x 13. Module reference: Filter group
Page 211
F
LT
M
ULTI
This is a multimode filter with a selectable slope of 6 or
12 dB/octave and resonance control. It is a multi-mode
filter with three outputs: one highpass (HP), one lowpass
(LP) and one bandpass (BP). All three outputs can be
used simultaneously. The cut-off frequency and the
resonance can be modulated from external sources. See also "Common Filter parameters”.
F
ILTER
MODES
The dB/Oct radio button can change the LP and HP outputs to 6dB slopes. The BP output however is
changed into an allpass output when the filter is in 6dB mode. An allpass filter will pass all frequencies,
but will have two effects on a sound. The first effect is that all partials are shifted in phase, higher partials
are shifted more as lower partials. This phase shifting effect is not heard unless the output is mixed with
other (allpass filtered) sounds of the same basic pitch. The second effect is that when the resonance is
opened a strong resonant peak occurs at the cutuff frequency. And this effect can be put to very good
use when e.g. filtering audio samples. The peak can significantly boost a small frequency band in the
sample, without filtering away the high or the low. Interesting application is to e.g. sweep the peak with
a triangle Lfo over a drumsample fed into a Line In input. Note that the allpass filter appears to be
inverted in respect to the input signal.
F
LT
S
TATIC
This is a static filter with selectable modes (LP/BP/HP),
frequency and resonance controls. The slope is fixed at
12 dB/octave. See also "Common Filter parameters”.
W
AH
W
AH
Wah-Wah modulation is often used for electric guitars to
get that funky “talking guitar” sound. Basically, the Wah-
Wah modulation is a lowpass/bandpass type of filter
that can be swept across the frequency range. During the sweep, the filter’s characteristics change slightly.
The Sweep range is preset to the ranges most often found on Wah-pedals and fits perfectly to the full
range of the M
ODWHEEL
. The Sweep can also be modulated from an external source on the Control
signal input. The control signal can be attenuated with the knob [A
TTENUATOR
T
YPE
I]. The Wah-Wah
sound is often enhanced by an additional Saturation or Overdrive module at the Wah-Wah output.
See also "Common Filter parameters”.
F
LT
V
OICE
The Voice Filter module is designed to simulate the part
of the vocal tract that produces the vowels. You can
select between a number of preset vowels and change
and modulate them to generate really amazing effects.
Waveforms with a lot of overtones, such as sawtooth or
pulse waves, are best suited to be used with the Voice Filter. This type of filtering is very suited to be
enhanced by just a little touch of Saturation distortion on the filter output.
