NORD MODULAR G2 V1.4x 13. Module reference: Filter group
Page 209
dB/O
CT
RADIO
BUTTONS
Here you select the filter roll-off (slope). The roll-off for a 1-pole filer is 6 dB/octave, 12 dB/
octave for a 2-pole filter, 18 dB/octave for a 3-pole filer and 24 dB/octave for a 4-pole filter.
Generally, the filter roll-off increases by 6 dB/octave for every pole a filter has.
F
ILTER
GRAPH
Some filter modules feature a graph to visually display the current filter characteristics. The
X-axis represents the frequency and the Y-axis the level. The gray horizontal line represents
the 0 dB level.
F
ILTER
DROP
-
DOWN
SELECTOR
Some filter modules have a drop-down roll-off selector. The different slopes of these modules
are not instantly available as in the modules with dB/Oct radio buttons. The advantage of this
is that these modules uses less Patch Load. However, changing roll-off in these modules will force the
Sound engine to recalculate and thus cause a brief moment of silence. So if you’re looking for lower Patch
Load, use these filter modules instead of the “radio button” ones.
P
ITCH
MODULATION
INPUT
There are one or more C
ONTROL
or D
YNAMIC
C
ONTROL
/A
UDIO
signal inputs for a
modulation source to control the cutoff frequency of the filter. There can also be a pitch
modulation attenuator next to the input of A
TTENUATOR
T
YPE
III. If the attenuator knob has
a triangle above it, click it to select 1:1 keyboard tracking of the cutoff frequency if the input is connected
to the Note output of the Keyboard module (see page 158). See “Pitch modulation” on page 78 for more
info.
F
LT
LP
This is a non-resonant lowpass filter with selectable
slope (6/12/18/24/30/36 dB/Oct.) and a modulation
input for cut-off frequency modulation. The passband is
flat with a gain of exactly 1 (unity gain).
Note that changing slope will force the Sound Engine to recalculate and thus cause a brief moment of
silence. See also "Common Filter parameters”.
F
LT
HP
This is a non-resonant highpass filter with selectable
slope (6/12/18/24/30/36 dB/Oct.) and a modulation
input for cut-off frequency modulation. The passband is
flat with a gain of exactly 1 (unity gain).
Note that changing slope will force the Sound Engine to recalculate and thus cause a brief moment of
silence. See also "Common Filter parameters”.
F
LT
N
ORD
This is a dynamic synthesizer filter with a slope of either
12 or 24 dB/octave. It is a multi-mode filter, providing a
highpass, a lowpass, a bandpass or a bandreject filter.
The cut-off frequency and the resonance can be
modulated from external sources.
