NORD MODULAR G2 V1.4x 13. Module reference: Shaper group
Page 205
C
LIP
This module can produce digital distortion by decreasing
the clip level limit(s) below the normal headroom.
S
HAPE
Toggle switch for the Symmetric and Asymmetric mode. If this is set to ‘Asym’, only the positive peaks
of a signal will be clipped. If this is set to ‘Sym’, both the positive and the negative peaks of a signal will
be clipped.
C
LIP
L
EV
Sets the initial clip level limit(s). See also "Common Shaper parameters”.
E
XAMPLE
OF
THE
C
LIP
MODULE
When the clipper module is in symmetrical Shape mode
the signal level drops significantly when the Clip Lev
knob is opened. A good solution is to use the module in
a feedback loop with a mixer module. The output of a
mixer is fed into the input of the Clip module and the
output of the Clip module is fed back into an input of
the Mixer. This will allow for deep clipping while the
clipped signal level will stay fixed between -64 and +64
units. This works well when e.g. a sawtooth waveform is
filtered with a high resonance bandpass filter and then
clipped, like in the example. Be sure to set the Shape
button of the Clip module to [Sym].
O
VERDRIVE
This module distorts an audio signal by amplifying the
input signal and force it to ‘hit the headroom’. The
special amplification characteristics makes this module
produce a warm, tube like distortion. There are four different distortion types available, each with
modulatable distortion depth control.
S
HAPE
Toggle switch for the Symmetric and Asymmetric mode. If this is set to ‘Asym’, only the positive peaks
of a signal will be clipped. If this is set to ‘Sym’, both the positive and the negative peaks of a signal will
be clipped.
T
YPE
Select type of overdrive distortion by clicking this scroll button. The alternatives are: Soft, Hard, Heavy
and Fat.
